Bad Elf Flex® Mini Standard
Bad Elf Flex® Mini Standard
Bad Elf Flex® Mini Standard
Bad Elf Flex® Mini Standard
Bad Elf Flex® Mini Standard
Bad Elf Flex® Mini Standard
Load image into Gallery viewer, Bad Elf Flex® Mini Standard
Load image into Gallery viewer, Bad Elf Flex® Mini Standard
Load image into Gallery viewer, Bad Elf Flex® Mini Standard
Load image into Gallery viewer, Bad Elf Flex® Mini Standard
Load image into Gallery viewer, Bad Elf Flex® Mini Standard
Load image into Gallery viewer, Bad Elf Flex® Mini Standard

SKU: BE-GPS-2500

Bad Elf Flex® Mini Standard

Vendor Bad Elf
MSRP $499.99
Sale price $499.99 MSRP
Sale Sold out
Unit price
/per


This item is a recurring or deferred purchase. By continuing, I agree to the cancellation policy and authorize you to charge my payment method at the prices, frequency and dates listed on this page until my order is fulfilled or I cancel, if permitted.
This is a pre order item. We will ship it when it comes in stock.
Error Quantity must be 1 or more

Adding product to your cart

Note: Our warehouse is currently shipping 2-4 days after the order is placed.

The perfect companion for your mapping-grade geospatial needs.

Introducing the next-generation Bad Elf Flex® Mini, a portable GNSS receiver set to revolutionize the geospatial industry. Mount the Mini on your phone, backpack, or monopod for one-handed use. Bluetooth connectivity provides a wireless connection to your phone or tablet. The free Bad Elf Flex app provides user-friendly checklist-based operations, ensuring a smooth experience for users of all skill levels.

Looking for sub-meter accuracy?  Check out the Flex Mini Extreme configuration.

  • Product Details
  • Specifications
  • Included Items

Positioning Engine

  • GPS: L1CA, L5L1CA, L5
  • GLONASS: G1G1
  • BeiDou: B1i, B2aB1i, B2a
  • Galileo: E1, E5aE1, E5a
  • QZSS
  • SBAS: WAAS, EGNOS, MSAS

Positioning Performance

  • 1.5m horizontal, 3m vertical (CEP)
  • Cold start time < 30 s typical (almanac and RTC)
  • Warm start time < 30 s typical (almanac and RTC)
  • Hot start time < 10 s (almanac, RTC, and position)
  • Maximum speed 1,850 kph (999 kts)
  • Maximum altitude 18,288 m (60,000 ft)
  • Differential options SBAS, Autonomous SBAS

Reporting Rate

  • Default: 1hz
  • Logging and SDK apps: up to 10hz

Interfaces

  • USB: USB device via USB-C receptacle
  • Bluetooth: Bluetooth V4.0 (HS) with integrated Class 1.5 PA Supports 3 simultaneous connections

Compatibility

  • Operating system: iOS, Android, Windows
  • Mobile App: The Bad Elf Flex App requires iOS 9.0+ or Android 9+
  • Connectivity: Bluetooth SPP, USB Serial

Operating Specifications

  • Operating: –4°F to +145°F (–20°C to +63°C)
  • Charging: 41F to +113°F (5°C to +45°C)

Environmental Specifications

  • Waterproof: IP67
  • Humidity: 5% to 95% non-condensing

Mechanical Specifications

  • Dimensions: 1.8” x 1.27” x 3.6” / 45.7mm x 32.5mm x 91mm
  • Weight: 5 oz / 143 g
  • Enclosure: Polycarbonate
  • Mounting: Bottom mount with 1/4”-20 thread

Battery Specifications

  • Bluetooth connected/logging: 24 hours

Product Specifications

  • USB Port: USB-C port for charging and ElfPort™ expansion
  • Accelerometer: 3-axis
  • Display: 128 x 128 pixel transflective LCD screen with backlight
  • Firmware: Field upgradeable via app or USB

Package Contents

  • Bad Elf Flex Mini Receiver
  • 3ft (90cm) USB-C cable
  • Accessory case
  • Quick Reference Guide
Product Details

Positioning Engine

  • GPS: L1CA, L5L1CA, L5
  • GLONASS: G1G1
  • BeiDou: B1i, B2aB1i, B2a
  • Galileo: E1, E5aE1, E5a
  • QZSS
  • SBAS: WAAS, EGNOS, MSAS

Positioning Performance

  • 1.5m horizontal, 3m vertical (CEP)
  • Cold start time < 30 s typical (almanac and RTC)
  • Warm start time < 30 s typical (almanac and RTC)
  • Hot start time < 10 s (almanac, RTC, and position)
  • Maximum speed 1,850 kph (999 kts)
  • Maximum altitude 18,288 m (60,000 ft)
  • Differential options SBAS, Autonomous SBAS

Reporting Rate

  • Default: 1hz
  • Logging and SDK apps: up to 10hz
Specifications

Interfaces

  • USB: USB device via USB-C receptacle
  • Bluetooth: Bluetooth V4.0 (HS) with integrated Class 1.5 PA Supports 3 simultaneous connections

Compatibility

  • Operating system: iOS, Android, Windows
  • Mobile App: The Bad Elf Flex App requires iOS 9.0+ or Android 9+
  • Connectivity: Bluetooth SPP, USB Serial

Operating Specifications

  • Operating: –4°F to +145°F (–20°C to +63°C)
  • Charging: 41F to +113°F (5°C to +45°C)

Environmental Specifications

  • Waterproof: IP67
  • Humidity: 5% to 95% non-condensing

Mechanical Specifications

  • Dimensions: 1.8” x 1.27” x 3.6” / 45.7mm x 32.5mm x 91mm
  • Weight: 5 oz / 143 g
  • Enclosure: Polycarbonate
  • Mounting: Bottom mount with 1/4”-20 thread

Battery Specifications

  • Bluetooth connected/logging: 24 hours

Product Specifications

  • USB Port: USB-C port for charging and ElfPort™ expansion
  • Accelerometer: 3-axis
  • Display: 128 x 128 pixel transflective LCD screen with backlight
  • Firmware: Field upgradeable via app or USB
Included Items

Package Contents

  • Bad Elf Flex Mini Receiver
  • 3ft (90cm) USB-C cable
  • Accessory case
  • Quick Reference Guide
